Star Micronics TSP143IV SK Series | Linerless Sticky Label Printer

The Star Micronics TSP143IV SK is a specialist direct thermal hardware solution purpose-built for linerless label printing. Representing the latest technical evolution of the industry-standard TSP100 series, this range is designed specifically for high-pressure Quick Service Restaurants (QSR), takeaway counters, dark kitchens, and fast-paced retail environments.

Unlike traditional label printers, linerless technology utilises paper rolls without silicone backing liners. This offers major operational advantages: it eliminates slick, discarded backing paper from kitchen floors, permits more labels per roll to reduce swap-out frequency during peak services, and allows variable-length label cutting to minimise paper waste.

Select Your Model and Part Number

Core Hardware Features

1. Integrated Label Taken Sensor (LTS)

The TSP143IV SK features a mechanical paper-retention sensor at the exit mouth. When printing multi-item online delivery orders or kitchen prep sequences, the printer holds the next job in the queue until the operator has physically removed the current sticky label. This prevents consecutive labels from packing together or sticking to one another during rapid ticket printing.

2. Specialised Anti-Stick Guillotine Cutter

Standard receipt printer cutters will jam immediately if used with adhesive media. The TSP143IV SK features a heavy-duty, teflon-coated guillotine cutter designed to slice clean through repositionable adhesives without accumulating sticky residue, ensuring a long operational lifespan.

3. Android Open Accessory (AOA) Protocol

The integrated USB-A port supports Android Open Accessory (AOA) technology. When connected to a compatible Android tablet via a standard USB cable, the printer establishes a direct, physical data connection while simultaneously delivering a 1.5A charge to the tablet. This prevents network dropouts on tablet-based till points.

4. Built-In CloudPRNT Next Technology

Running on the modern MQTT communication protocol, Star's CloudPRNT Next allows the printer to communicate directly with web servers. It pulls and prints online orders from platforms such as Shopify, WooCommerce, Deliveroo, or Uber Eats web portals automatically, bypassing the need for a local PC or tablet to act as an intermediary bridge.

Technical Specifications

• Print Method: Direct Line Thermal

• Media Type: Linerless Labels (Repositionable "Re-Stick" & Permanent)

• Print Resolution: 203 dpi (8 dots per mm)

• Print Speed: Up to 180 mm / second

• Paper Specifications: * Width: 80mm standard (Adjustable down to 40mm using internal guides)

  • Roll Diameter: Up to 83mm

  • Adhesive Compatibility: Approved linerless media brands (e.g., MaxStick, Restick)

• Autocutter: Teflon-coated guillotine cutter (Partial cut, heavy-duty)

• Advanced Sensors: Label Taken Sensor (LTS), Paper End, Cover Open

• Operating System Support: Windows, macOS, iOS, Android, Linux, WebPRNT, CloudPRNT

• Dimensions: 140 mm (W) x 169 mm (D) x 123 mm (H)

• Weight: 1.3 kg

• Warranty: 4-Year Manufacturer Warranty

• Box Contents: Printer, Power Cable, USB-C to USB-A Cable, Ethernet Cable, Paper Guide, Quick Setup Manual

Industry Applications

• Quick Service Restaurants (QSR) & Takeaways: Used at the packing station to print variable-length tickets that stick directly to brown paper delivery bags, plastic containers, or coffee cups, removing the need for plastic staples or tape.

• Kitchen Food Prep & Safety: Ideal for printing internal food rotation labels, ingredient lists, and allergen alerts. Repositionable labels stick firmly to stainless steel inserts or plastic tubs but peel away clean without leaving a gummy glue residue before washing.

• Click & Collect / Retail Logistics: Perfect for rapid printing of dispatch labels and item identification tags directly onto inventory boxes during warehouse sorting.

Key Frequently Asked Questions (FAQ)

What type of paper rolls does the TSP143IV SK require?

This printer cannot use standard thermal receipt paper or traditional die-cut labels with backing sheets. It requires specialised "linerless thermal label paper" (such as MaxStick or Star-approved alternatives). These rolls feature a special release coating on the front and a repositionable adhesive on the back, allowing the paper to be wound cleanly onto the roll without sticking to itself.

Shop MaxStick Linerless Labels

Can I use this printer with third-party delivery apps like Deliveroo, Just Eat or Uber Eats?

Yes. For fixed countertop installations, the UE SK model (39473390) connects directly to your internet router via an Ethernet cable, allowing delivery tablets on the same network to send orders straight to the kitchen. For mobile food trucks or setups where a wired router is out of reach, the SK X4 model (39473990) provides the necessary wireless flexibility via Dual-Band WiFi or Bluetooth.

Does this printer work with an iPad via a direct USB cable?

No. The USB-A port on the TSP143IV SK utilises the Android Open Accessory (AOA) protocol, which allows direct data transmission and charging only for Android tablets. An iPad will receive power from the port but cannot communicate data over the cable. To connect an iPad, you must use network methods: connect via an Ethernet network cable (UE model) or over WiFi/Bluetooth (X4 model).

What is the difference between "Re-Stick" linerless labels and standard labels?

Standard labels are cut to a fixed size (e.g., 4" x 6") and mounted on a silicone liner sheet with permanent adhesive. Once stuck down, they are difficult to remove. "Re-Stick" linerless labels have no backing sheet, can be cut by the printer to the exact length of the text, and feature a lower-tack adhesive. This allows staff to stick the label to a bag or coffee cup, peel it off, and re-apply it elsewhere without tearing the packaging or leaving glue behind.

Does this printer require ink or toner?

No. The TSP143IV SK utilises direct thermal printing technology. The printhead applies heat directly to heat-sensitive linerless label paper to create the text and graphics, eliminating ongoing ribbon or ink cartridge costs.
